Actoris ParLED

AL2595 (Actoris ParLED); AL2596 (Actoris ParLED RGBW)

First in a series of specialized models for the theatrical sector, this product features an RGBWW LED light source, that produces warm color temperatures perfect to match any complexion or scenery on stage through its replication of natural pastel colors and CRI rating greater than 90. The color temperature can also be digitally adjusted between 2500K through 6500K.

There is an increasing demand for smaller, silent, and simpler light fixtures that produce an excellent and efficient light beam. The Actoris ParLED embodies these qualities is a small form factor fixture that only weighs 6 kilograms and is 306 mm in length.

The implementation of a special warm white LEDs does not adversely affect the luminous efficiency: the Actoris ParLED is positioned at the top of its category, featuring a lumen output of 3400 lumens.

The Actoris ParLED features extremely silent operation, thanks to use of special silenced axial fans.

With a zoom range of 4 to 53° via its motorized zoom, a 24-bit electronic dimmer with five curves, 4 individually selectable operating modes, and its color range, makes the Actoris ParLED one of the smallest, most versatile fixtures on the market.

Using the same LED optical system as the Claypaky MINI-B WW range, you can use Actoris ParLED with these products for balanced color consistency. Barndoors and frames for frost and gel filters are available as optional accessories.

Actoris ParLED is one model being introduced through the new Actoris series by ADB, designed specifically for theatres and marketed by Claypaky and its dealer network.

  • Light Source
    7 x 40W RGBWW Osram LEDs
  • Zoom range
    Motorized 4° to 53° zoom range
  • Effects
    RGB+WW colour mixing 16bit; Linear CTB, 6500K to 2500K; Preset macro colors; High resolution electronic Dimmer - 24 bit
Data Sheet DMX Channels Photometrics PDF

Highlights

Specs

Save as pdf and print

LIGHT SOURCE TYPE

  • 7x Osram 40W RGB+WW LEDs (Actoris ParLED)
  • 7x Osram 40W RGBW LEDs (Actoris ParLED RGBW)
  • LED life expectancy: 50000hrs (20000Hrs L70*)
    *It may vary depending on various factors, as type of use and environment

PHOTOMETRIC DATA

  • Zoom range: 4°- 53°
  • 3380 Lumen Output (Integrating Sphere)
  • Front lens diameter: 150mm
  • High efficiency optical system

NOISE LEVEL

  • RnR mode (Dimmer @100%): 44.6 dBA
  • Boost mode (Dimmer @100%): 36.6 dBA
  • Theatre mode (Dimmer @100%): 31.5 dBA
  • SLN mode (Dimmer @100%): 28.0 dBA
  • Fanless mode (Dimmer @100%): 24.6 dBA

CONTROL and CONNECTIONS

  • Personalities: Two different operating modes, 13/17 DMX channel
  • Control Protocol: DMX, Art-Net, RDM, sACN
  • DMX and RDM connectors: Locking 5 pin XLR IN/THRU
  • Ethernet port: RJ45 IN
  • Power connector: PowerCon True1 IN/OUT
  • Built In Web Server

DYNAMIC EFFECTS

  • Colors:
    • Colour mixing 16bit
    • Linear CTB, 6500K to 2500K (Actoris ParLED)
    • Linear CTO, 2500K to 6500K (Actoris ParLED RGBW)
    • Preset macro colors
  • Beam:
    • Motorized Zoom
  • Dimmer/Shutter:
    • High resolution electronic Dimmer - 24 bit
    • High speed electronic Strobe

HARDWARE and SOFTWARE

  • Display Graphic LCD backlit b/w Display
  • Firmware upload from another fixture
  • Firmware Upgrade via Web Server
  • Diagnostic
  • DMX monitoring
  • Remote access through RDM
  • CloudIO compatibility

HOUSING

  • Aluminum and steel structure with plastic covers
  • Two side handles for transportation
  • IP20 protection rate

WORKING POSITION

  • Working in any position
  • Hanging system: built in brackets
  • Optional safety chain

ELECTRICAL

  • Operating Voltage: 100-240V, 50/60 Hz - In/Out Max 8(3) fixtures @ 200-240Vac (@ 100-120Vac)
  • Power Supply: Electronic auto range with active PFC
  • Max Power consumption: 326W

THERMAL SPECIFICATION

  • Max ambient temperature 45°C (113°F)
  • Min ambient temperature -20°C (-4°F)
  • Max temperature of the external surface 90°C (194°F)
  • Total heat dissipation: 1110 BTU/hr ±10% / 1170 kJ/hr ±10%

SAFETY SPECS

  • Minimum distance of illuminated objects 0.2 meters (8”)
  • Minimum distance from flammable materials 0.2 meters (8”)
  • Thermally protected power supply (overheating and cooling failure)
  • Forced ventilation with axial fans
  • T6.3A fuse

COMPLIANCE

  • CE: conforms to the European Directives
  • UKCA: conforms to UK Regulations
  • EAC: conforms to EurAseC Regulations
  • cMETus Listed

PACKAGING

  • Carton box + Polystyrene
  • Carton box + Foam Shell
  • Flight case + Foam shell (8 positions)

WEIGHT - SIZE

  • 5.7 Kg (12.6 lbs)
  • 341mm x 325mm x 275mm
  • Distance between two fixtures 400mm

ACCESSORIES

  • Power cord: CAB02B/802 (included)
  • Frame holder: AA2017000102 (optional)
  • Gel holder: AA2018000102 (optional)
  • Barndoors: AA2019000102 (optional)
  • Egg crate: CA3002000100 (optional)
  • Frost filter 5°: AA2021000102 (optional)
  • Frost filter 2°: AA2020000102 (optional)
  • Foam shell: F21332-801 (optional)
  • Flight case: CF1017 (optional)
  • Safety Chain: 105041-003 (optional)
  • Clamp: C21070 (optional)
  • Power conTrue1 connector: CON00O (optional)
