Axcor Profile 600

C61705 (600); CL3016 (600 Teatro); CL3017 (600 Teatro HC)

In the crowded world of medium-high power lights, the Axcor Profile 600 stands out for its excellent combination of high performance, exceptional light quality, and versatility of use. It fits a 500 W white LED engine, available in two versions: with high output 6500K color temperature, or – alternatively – with 5600K color temperature and a CRI of around 90.

The luminous efficiency is among the highest in this power category, and – if necessary – it can be further increased by about 25% thanks to “boost mode” (available on the standard version and on the HC version), making Axcor Profile 600 a perfect tool for tours and large events.
A wide zoom range from 5.3° to 47.2° (1:9 ratio) means the light can be used in a variety of situations, including those for which a narrow angle is best.
The completeness of its color section, its great wealth of visual effects, its framing system implemented with technological devices that enhance its precision and versatility, the possibility of using it as a wash light, make the Axcor Profile 600 an essential benchmark for all modern entertainment uses.

The Axcor Profile 600 Teatro is a special version of the Axcor Profile 600 ST that features an updated cooling system and mechanisms to significantly reduce the unit’s acoustical footprint. Available in two different CRI versions, this fixture is ideal for applications where noise is a concern in venues such as theatres, television studios, opera houses, conference halls, and more.

Axcor Profile 600 HC (code C61706), Axcor Profile 600 ST (code C61708)  and Axcor Profile 600 HC-ST  (code C61709) are available on demand

  • Light Source
    500W White LED Engine
  • Zoom range
    5.3°- 47.2° linear Zoom
  • Effects
    Linear CMY color mixing; Linear CTO; 5-color wheel; 4-blades Framing system; 1 Rotating gobo wheel with 7 HD Indexable and replaceable gobos; Variable “soft edge” frost 0-100% linear; animation wheel; 4 Facets prism; Motorized iris; Motorized Zoom and Focus; High resolution electronic Dimmer - 24 bit, 4 curves; High speed electronic Shutter and Strobe
Data Sheet DMX Channels Photometrics PDF (600)

Specs

Save as pdf and print

MODEL

  • Axcor Profile 600 (C61705)
  • Axcor Profile 600 HC (C61706)
  • Axcor Profile 600 ST (C61708)
  • Axcor Profile 600 TEATRO (CL3016)
  • Axcor Profile 600 HC-TEATRO (CL3017)

LIGHT SOURCE TYPE

  • 500W White LED Engine
  • CRI: 70+, CT 6500K (600 / 600ST / 600Teatro)
  • CRI: 90+, CT 5600K (600HC / 600HC-ST / 600HC Teatro)
  • LED life expectancy: 40000Hrs L70*
    *It may vary depending on various factors, as type of use and environment

PHOTOMETRIC DATA

  • Zoom range: 5.3°- 47.2°
  • Front lens diameter: 132mm
  • High efficiency optical system
  • Axcor Profile 600: 18100 Lumen Output
  • Axcor Profile 600 HC: 14300 Lumen Output
  • Axcor Profile 600 ST: 15200 Lumen Output
  • Axcor Profile 600 HC-ST: 11500 Lumen Output
  • Axcor Profile 600 Teatro: 15500 Lumen Output
  • Axcor Profile 600 HC Teatro: 14000 Lumen Output

NOISE LEVEL

  • Axcor Profile 600 series
  • Standard Mode; LED @ 500W: 45.0 dBA
  • Standard Mode; LED @ 400W: 41.5 dBA
  • Axcor Profile 600 Teatro series
  • Standard Mode; LED @ 500W: 42.5 dBA
  • Silent Mode; LED @ 400W: 38.5 dBA
  • Silent Mode; LED @ 300W: 35.0 dBA

CONTROL and CONNECTIONS

  • Personalities: 2 modes with 40/44 control channels
  • Control Protocol: DMX, Art-Net, RDM, sACN
  • DMX and RDM connectors: Locking 3 and 5 pin XLR IN/THRU
  • Ethernet port: RJ45 IN
  • Power connector: PowerCon True1 IN/OUT
  • Built In Web Server

DYNAMIC EFFECTS

  • Colours:
    • Linear CMY colour mixing
    • Linear CTO (6500K – 3200K)
    • Fixed color wheel with 5 dichroic colors
  • Gobos:
    • 1 Rotating gobo wheel with 7 HD Indexable and replaceable gobos
    • Ext diam. 25.9mm
    • Image diam. 20mm
    • Thickness 1.0mm
  • Framing system:
    • 4 blades that move separately with +/- 90° rotation of the full system
    • Motorized framing system with 4 focal planes
    • Smooth, flexible blade movements at variable speed
    • A "total curtain" effect made separately by each of the 4 blades, in many - shapes and colors. / Small and large
      dynamic profiles
  • Frost:
    • Variable “soft edge” frost 0-100% linear
  • Rotating Effects
    • Aluminum animation wheel with continuous rotation in both direction at variable speed
    • 4 Facets prism with rotation in both direction at variable speed
  • Iris:
    • Motorized with variable pulse and random effects
  • Movement:
    • Tilt: 268° - 16bit
    • Pan: 540° - 16bit
    • Accuracy: Resolution ± 0.23° (Range 0.46°)
    • Automatic repositioning
    • Fast/Normal speed selectable by Function channel
    • Mechanical Pan/Tilt lock for safe transportation and maintenance
  • Beam:
    • Motorized Zoom and Focus
  • Dimmer/Shutter:
    • High resolution electronic Dimmer - 24 bit, 4 curves
    • High speed electronic Shutter and Strobe

HARDWARE and SOFTWARE

  • Long life self-charging battery
  • Display Graphic LCD backlit b/w Display
  • Firmware upload from another fixture
  • Firmware Upgrade via Web Server
  • Diagnostic
  • DMX monitoring
  • Remote access through RDM
  • CloudIO compatibility

HOUSING

  • Aluminum and steel structure with plastic covers
  • Two side handles for transportation
  • IP20 protection rate

WORKING POSITION

  • Working in any position
  • Hanging system: with fast-lock omega clamps (1/4 turn) on the base
  • Optional safety chain

ELECTRICAL

  • Operating Voltage: 100-240V, 50/60 Hz
  • Max Power consumption: 800VA

THERMAL SPECIFICATION

  • Max ambient temperature 40°C (104°F)
  • Min ambient temperature -10°C (14°F)
  • Max temperature of the external surface 90°C (194°F)
  • Total heat dissipation: 2390 BTU/hr ±10% / 2520 kJ/hr ±10%

SAFETY SPECS

  • Minimum distance of illuminated objects 3 meters (9’ 10’’)
  • Minimum distance from flammable materials 0.2 meters (8”)
  • Thermally protected power supply (overheating and cooling failure)
  • Forced ventilation with axial fans

COMPLIANCE

  • CE: conforms to the European Directives
  • UKCA: conforms to UK Regulations
  • cETLus Listed

PACKAGING

  • Carton box + Polystyrene
  • Carton box + Foam shell
  • Flight case + Foam shell (2 positions)

WEIGHT - SIZE

  • 33 Kg (72.7 lbs)
  • 329x388mm (base dimension) – 785mm with vertical head (h)
  • Distance between two fixtures 700mm

ACCESSORIES

  • Omega clamps: 2x183102/805 (included)
  • ETL Power cord 1.5mt. (bare end with IP65 PowerConTrue1 connector): CAB02B/802 (included)
  • Foam shell: F21310/001 (optional)
  • Flight case (2 positions): F21311 (optional)
  • Safety Chain: 105041/001 (optional)
  • Optional static gobo: C61785
