Buddylight

CA1010 (Box); CA1011 (Tag); CA1012 (Holder)

NEW

The Buddylight is Claypaky’s brand new automated followspot system. It follows performers and speakers automatically, in a quick and easy way.

The Buddylight can be used either in an Art-Net or DMX network – by setting up control priority management with the console – or in standalone mode, where it really comes into its element!

Setting it up has been designed to be quick and user-friendly for all users, thanks to a simplified, flexible installation.

The maximum tracking area can extend to 15×15 m (16.4×16.4 yards). Anchors should be placed to mark out the space within which the performer can move.

The tags, which the performer has to wear so that the followspot can follow them, are designed so they can quickly access the main functions of the spotlight and its automated control.

The Buddylight marks a further step towards ever-greater entertainment light automation. It is perfect for theatres, auditoriums and conference rooms. The Buddylight is a new, practical, user-friendly Claypaky system suitable for all budgets. A true buddy who will accompany your performance!

Do you want to know more about Buddylight? Go to the specific page.

Data Sheet

Highlights

Automated followspot

Automated followspot

The Buddylight is Claypaky’s brand new automated followspot system. It follows performers and speakers automatically, in a quick and easy way.
In an Art-Net or DMX network or in standalone mode

In an Art-Net or DMX network or in standalone mode

The Buddylight can be used either in an Art-Net or DMX network – by setting up control priority management with the console – or in standalone mode, where it really comes into its element!
15x15 m (16.4x16.4 yards)

15x15 m (16.4x16.4 yards)

The maximum tracking area can extend up to 15×15 m (16.4×16.4 yards). Anchors should be placed to mark out the space within which the performer can move.

Specs Save as pdf

Save as pdf and print

STARTER KIT (CA1015)

STARTER KIT CONSISTS OF:
- Buddylight box ETL: X 1
- Tag User / Anchor ETL: X 10 (8 anchors & 2 trackers)
- Tag holder ETL: X 10
- Buddylight Flightcase: X 1

CHARACTERISTICS:
- Tracking area: 15 X 15
- Installation requirements:
  - Box & Tags must be installed within the tracking area
  - Followspot lights can be installed outside the tracking area. However, the greater the distance between the followspot light and the tracking area, the greater the imprecision in the light movement will be
- Characteristics: MAX n° of trackable people: 4

ITEMS REQUIRED FOR CALIBRATION (NOT INCLUDED IN KIT)
- CA8003C70102

COMPATIBILITY:
- https://www.claypaky.it/en/buddylight/

BUDDYLIGHT BOX (CA1010)

ELECTRICAL RATINGS:
- Input Volt: 100 - 240 Vac
- Frequency: 50 / 60 Hz
- Input power: 30 W
MECHANICAL DIMENSIONS:
- Width: 199 mm 7,8 In
- Length: 260 mm 10,2 In
- Height: 87 mm 3,4 In
- Weight: 1,2 Kg 2,65 Ibs
CONTROL & CONNECTIONS:
- Protocols: Art-Net
- Connectors:
  - 1x RJ45 10 / 100 / 1000 (IN)
  - 1x RJ45 10 / 100 (OUT)
  - 1x USB IN type A
- Wireless:
  - 1x WiFi module 2.4 GHz
  - 1x UWB
- Power Con: PowerCon True1 IN/OUT
- Web interface: Built-in

CHARACTERISTICS
- MAX N° of box within the tracking area: 4
- MAX N° of followspot controlled by one box: 1
PACKAGING
- Carton box

TAG (CA1011)

MECHANICAL DIMENSIONS:
- Width: 42 mm 1,7 In
- Length: 27 mm 1,1 In
- Height: 85 mm 3,3 In
- Weight: 0,05 Kg 0,11 lbs
CHARACTERISTICS:
- MAX battery life: 8 Hrs
- N° of Tags that must be worn: 2
PACKAGING:
- Carton box

HOLDER (CA1012)

ELECTRICAL RATINGS
- Input Volt: 100 – 240 Vac
- Frequency: 50 / 60 Hz
- Input power: 16 W
MECHANICAL DIMENSIONS
- Width: 66 mm 2,6 In
- Length: 63 mm 2,5 In
- Height: 99 mm 3,9 In
- Weight: 0,2 Kg 0,44 lbs
HOUSING
- Hanging system:
  - Screw (threaded hole 3/8’’ 16)
  - Cable ties
  - Clamp (thru-hole Ø 10,5 mm)
PACKAGING:
- Carton box

ACCESSORIES

Leica Disto S910 PRO PACK: CA8003C70102
