Panify

CA3006
Claypaky Panify

Panify is a new solution for more creative possibilities, allowing you to turn every static, non-moving fixture into dynamic effects. The Panify is not limited to fixtures and could be used to turn scenery, signs, screens, and more. The unit is IP66-rated and can be used and hung in any position.

Claypaky focuses on developing innovative and useful solutions for lighting taking a bold new step with the development of the Panify. The Panify lets you take a static, non-moving fixture and turn it for dynamic effects.

The Panify is designed to accept not only Claypaky products such as the Tambora Batten or MINI-B PARLED AQUA but also most static lights from other brands that cannot pan. The Panify offers endless pan operation and various speeds and can accept fixtures up to 30 kilograms (66 pounds). The unit can spin up to 43 RPM to provide unparalleled effects.

The Panify has two power inputs – one input for the unit itself and the other for the mounted fixture. Because of the innovative design of the unit’s crossbeam, the power is routed from the enclosure to the crossbeam where the mounted fixture connects for its power and DMX; so, there are no concerns of tangled power or DMX cables when using the endless pan feature. The Panify only draws about 220VA of power and only requires a few channels of DMX to operate. The unit is already wireless DMX-ready, so you do not have to run additional DMX cabling.

The Panify is not limited to fixtures and could be used to turn scenery, signs, screens, and more. The unit is IP66-rated and can be used and hung in any position. The Panify expands and extends the usefulness of static fixtures or whatever you need to turn for your productions.  Its flexibility and versatility allow the Panify to be anything you need it to be.

  • Effects
    Advanced tool turning fixtures, scenery, signs, screens into dynamic effects; Endless PAN rotation at various speed (up to 50 RPM); Maximum load to be applied: 30kg (66 lbs); Any hanging positions; DMX and WDMX (optional) controllable
Data Sheet DMX Channels

Highlights

Specs

Save as pdf and print



CONTROL and CONNECTIONS

  • Personalities:
    • Single mode with 5 control channels
  • Protocol:
    • DMX, Art-Net, RDM, sACN
    • DMX (Base to Head)
  • Connectors:
    • Locking 5 pin XLR IN/OUT (Base)
    • Locking 5 pin XLR IN/OUT (Head)
    • RJ45 IN (Base)
  • Power con:
    • PowerCon True1 IN/OUT (Base)
    • PowerCon True1 OUT (Head)
  • Web Server:
    • Built-in
  • CloudIO:
    • Fully compatible

DYNAMIC EFFECTS

  • Rotating Effects:
    • Pan endless
    • MAX rotating speed: 43 rpm
  • Max applicable weight:
    • 30Kg with the weight of the fixture balanced on the Panify

HARDWARE and SOFTWARE

  • Long life self-charging battery
  • Display Graphic LCD backlit b/w Display
  • Firmware upload from another fixture
  • Firmware Upgrade via Web Server
  • Diagnostic
  • DMX monitoring
  • Remote access through RDM

HOUSING

  • Aluminum and steel structure with plastic covers
  • Two side handles for transportation
  • IP66 protection rate

WORKING POSITION

  • Working in any position
  • Hanging system: with fast-lock omega clamps (1/4 turn) on the base
  • Optional safety chain

ELECTRICAL

  • Operating Voltage: 100-240V, 50/60 Hz
  • Power Supply: Electronic auto range with active PFC
  • Max Power consumption: 220VA
  • Mains Out: 2300 VA @ 230V; 1250 VA @ 110V

THERMAL SPECIFICATION

  • Max ambient temperature 45°C (113°F)
  • Min ambient temperature -20°C (-4°F)

SAFETY SPECS

  • Fuse 4A – 250V

COMPLIANCE

  • CE Marking (in conformity to the following)
    • 2014/35/EU - Low Voltage Directive(LDV)
    • 2014/30/EU Electromagnetic compatibility (EMC)
    • 2011/65/EU - Restriction of the use of certain hazardous substance (RoHS)
  • UKCA conforms to UK Regulations:
    • S.I. 2016 N. 1101
    • S.I. 2016 N.1091
    • S.I. 2012 N.3032
  • cMETus LiSTED:
    • UL 962
    • CSA C22.2 N. 68-18

PACKAGING

  • Carton box + Polystyrene
  • Flight case + Foam shell (4 position)

WEIGHT & SIZE

  • Weight:
    • 13.8 Kg (30.4 lbs)
  • Base dimensions:
    • 390,8 x 295 mm
    • 15,39 x 11,61 In
  • Height (h):
    • 252,8 mm
    • 9,95 In
  • Distribution between 2 fixture:
    • It varies depending on the fixture mouted on the product

ACCESSORIES

  • ETL Mains cable, 1.5mt. (Bare Ends / IP65 PowerConTrue1 connector): CAB02B-802 (included)
  • Omega bracket: 2x 183102/805 (included)
  • Power cables 0.5mt.: 2x CAB0PR/801 (included)
  • DMX cable 0.5mt.: CAB0PS/801 (included)
  • Safety chains 0.5mt.: 2x FUN00C/001 (included)
  • Screws/Bolts/Washers: 4x418100-801 (included)
  • Clamp: C21070 (optional)
  • Safety chain: 105041-003 (optional)
  • Power Con True1 connector: CON00O (optional)
  • Foam shell: F21329/001 (optional)
  • Flight case 4 pos.: CF1016 (optional)
  • Universal bracket: CA3017000102 (optional)
