Rhapsodya

CL3024

Rhapsodya emerges as a groundbreaking, low-noise multi-spectral RGBAL LED fixture meticulously designed for various applications such as touring, live events, theatre, and TV production, and managed by a specially crafted, internally developed firmware algorithm.
It is an evolution of Sinfonya, particularly regarding the focus on quality of optics and color management, and the whisper-quiet operation even at full output. Rhapsodya has a stunning new product design that is sleek and modern, with a double power output compared to Sinfonya.

Besides the innovative features in common with Sinfonya, such as ACCUFRAME^TM, a framing system employing dual focal planes, achieving an astounding 40-fold increase in precision when compared to conventional framing systems and TONEDOWN^TM, which ensures whisper-quiet operation at just 27dB, Absolute Position control for advanced PAN & TILT capabilities, and LINEGUARD, a new frost system employing two pairs of blades, Rhapsodya gives a technological boost thanks to the new features: AccuTune a precise control over the multicolor LED engine thanks to a new algorithm for vibrant and rich colors optimized for both stage and TV.
COLORSTRING, is an individual LED control for a high level of graphics and color effects, empowering you to create intricate and dynamic lighting displays.
Furthermore, the fixture boasts a cutting-edge Proprietary Optical System, offering an impressive 6.2° to 63.3° Zoom range.

Rhapsodya is more than just a fixture; it’s your backstage partner, your on-air star, and your roadie’s dream. Explore its exceptional features and witness the future of lighting innovation.

Light Source

1200W RGBAL LED Engine
Light Output

24,000 lm (in integrating sphere)
Zoom range

6.2°- 63.3°
Effects

Digital color filters; Individual Led Stripe Control (ColorString); 2 wheels with 6 HD interchangeable rotating gobos each; Animation wheel with X/Y insertion and rotation; 4-facets prism with rotation in both directions at variable speed; Color wheel expansion (with additional deep red, deep green and deep blue options)

Data Sheet DMX Channels Photometrics PDF

Highlights

ACCUFRAME™ - A new framing system

ACCUFRAME™ - A new framing system

By utilizing two focal planes, a much higher edge focus has been achieved, still allowing the creation of triangular and curtain effects. The different motorization of the blades’ movements is now 40 times more precise than traditional framing systems, giving limitless scope and possibilities on stage while saving time on programming and re-focusing.
LINEGUARD - A new frost system

LINEGUARD - A new frost system

Traditionally, a single blade would not provide a uniform effect, our new approach using pairs provides much higher beam uniformity. By using two pairs, and by placing them properly, greater soft edges and uniform wash effects are achieved for better looks and performance, and truly incremental adjustments of frost levels.
ABSOLUTE POSITION - For advanced PAN & TILT control

ABSOLUTE POSITION - For advanced PAN & TILT control

A proprietary sensor inside the pan and tilt motors remembers the position in real-time, allowing for precision re-positioning crucially with no movement when doing a hard reset. This new system gives a much higher precision, a feature that will be really appreciated since the time for refocusing before the show is always limited.
TONEDOWN™ - For noise levels as low as 27dB

TONEDOWN™ - For noise levels as low as 27dB

Claypaky redesigned the cooling system: even at full output the noise is just 27dB. In addition to this, the fan has been taken out of the base. This reduces noise further on stage and removes black noise from other frequencies that can sometimes be annoying.
Tonedown™ is a feature that was impossible to achieve before and lets designers create room for captivating new choreography.
COLORMATCH In-field calibration

COLORMATCH In-field calibration

With the new calibration feature integrated with Claypaky’s CloudIO software, you can easily tune any fixture on stage at the same light output and color temperature levels. Even older fixtures can have the color sampled and measured before being imported using the digital filter option. This guarantees consistent, perfectly tuned lighting, for an uninterrupted experience.
ACCUTUNE - A new color control algorithm

ACCUTUNE - A new color control algorithm

A new algorithm for vibrant and rich colors.
A sophisticated, internally developed firmware algorithm gives us precise control over the beam in the multicolor engine. This provides vibrant, rich colors and a balanced, consistent white, optimized for stage or TV, with high CRI and TLCI levels.
COLORSTRING - Individual LED stripe control

COLORSTRING - Individual LED stripe control

An individual LED control for a high level of graphics and color effects. A new system enabling individual control of 4 independent LED stripes of the multicolor engine for a high level of graphics and color effects.
Color Wheel Expansion

Color Wheel Expansion

Rhapsodya’s color wheel builds upon the foundation of Sinfonya, offering additional red, green, and blue options. This expansion adds three crucial points to the gamut that were unattainable with the engine’s native colors. With an extended color palette, your creative horizons are limitless. Craft captivating and unique lighting designs that set you apart.

Specs Save as pdf

Save as pdf and print

LIGHT SOURCE TYPE

LED RGBAL
Power: 1200W
CRI: Up to 94
Colour Temperature: 2500 to 10.000K
Lamp life expectancy: 40.000 Hrs
*It may vary depending on various factors, as type of use and environment

PHOTOMETRIC DATA

Zoom range: 6,2° to 63,3°
24.000 Lumen Output (Integrating Sphere)
Front lens diameter: 180mm
Optical system: 14 high efficiency lenses

NOISE LEVEL

Controlled by:
- Able to control linearly fans speed
Fixed presets: 27dBA/ 30dBA / 35dBA
Fanless mode: with reduced output

CONTROL and CONNECTIONS

Personalities: Three (3) modes with 62 / 54 / 46 control channels + separate control of the engine string (20 channels)
Control Protocol: DMX, Art-Net, RDM, sACN, CRMX lumen Radio (Optional)
Connectors:
- Locking 5 pin XLR IN/THRU
- 2 x RJ45 IN/OUT
Power connector: PowerCon True1 IN
Web Server: built-in
CloudIO:
- Fully compatible
- On-field calibration for color consistency

DYNAMIC EFFECTS

Colours:
- RGBAL control
- Virtual CTO
- +/- Green correction
- Adjustable CRI
- Digital Color Filters
Gobos:
- 2 rotating gobo wheels with 6 HD Indexable and replaceable gobos: Ext diam. 32.8 mm Image diam. 27 mm Thickness 1.1mm
Framing system:
- 4 blades with +/- 60° rotation of the full system, 2 focal planes
- “Total Curtain" effect allowing the full blackout with each single blade
Frost:
- Linear heavy frost 5° for wash effect (Fixed)
- Light frost 1° for soft diffusion (interchangeble)
Rotating Effects:
- 1 Aluminum animation wheel with continuous rotation in both direction at variable speed - XY movement
- 1 Four-Facet prism with rotation in both directions at variable speed
Iris:
- 16 blades motorized with variable pulse and random effects
Movement:
- Tilt: 270° - 16bit
- Pan: 540° - 16bit
- Accuracy: Resolution ± 0.12° (± 0° 7' 12") Range 0.24° (0° 14' 24")
- Absolute position
- Automatic repositioning
- Mechanical Pan/Tilt lock for safe transportation and maintenance
- Tilt safety brake system
Beam:
- Motorized Zoom and Focus
- Autofocus
Dimmer/Shutter:
- High speed electronic shutter and Strobe
- High resolution dimmer 24 bit, 3 curves

HARDWARE and SOFTWARE

Long life self-charging battery
Display Graphic LCD backlit b/w display
Firmware upload from another fixture
Firmware Upgrade via Web Server
Diagnostic
DMX monitoring
Remote access through RDM

HOUSING

Aluminum and steel structure with plastic covers
Two side handles for transportation
IP20 protection rate
Working in any position
Hanging system: with fast-lock omega clamps (1/4 turn) on the base
Optional safety chain

ELECTRICAL

Operating Voltage: 100-120 / 200-240V, 50/60 Hz
Power Supply: Electronic auto range with active PFC
Max Power consumption: 1600W

THERMAL SPECIFICATION

Max ambient temperature 40°C (104°F)
Min ambient temperature -20°C (-4°F)
Max temperature of the external surface 40°C (104°F)
Total heat dissipation: 5294 BTU/hr ±10% / 5580 kJ/hr ±10%

SAFETY SPECIFICATIONS

Minimum distance of illuminated objects 2 meters (6’7”)
Minimum distance from flammable materials 0.2 meters (8”)
Bipolar circuit breaker with thermal protected power supply (overheating and cooling failure)
Forced ventilation with axial fans

COMPLIANCE

CE Marking:(in conformity to the following)
- 2014/53/EU - Radio Equipment Directive (RED)
- 2011/65/EU - Restriction of the use of certain hazardous substances (RoHS)
- 2009/125/EC - EcoDesign requirements for Energy-related Products (ErP)
UKCA: conforms to UK Regulations:
- S.I. 2017 N.1206
- S.I. 2012 N.3032
- S.I. 2021 N.745
cETLus LISTED:
- UL 1573:2003
- CSA C22.2 N.166:2015

PACKAGING

Green/Total carton box
Flight case + Foam shell (1 position)

WEIGHT - SIZE

48.1 Kg (106.04 lbs)
Base dimension 452 x 407 mm 17,79 x 16,02 in
Height with vertical head (h) 859 mm 33,82 in
Distance between two fixtures 850mm

ACCESSORIES

Omega clamps: 2x183102-805 (included)
Power cord: ETL Power cord Cord 1.5 mt. ( bare end with IP65 PowerConTrue1 connector): CAB0TF-802 (included)
Flight case 1 positions: CF1028 (Optional)
Safety Chain: 105041-003 (optional)
Clamp: C21070 (Optional)
