Claypaky Tambora Linear 100

Following its successful range of LED bars introduced last year, Claypaky has expanded the Tambora family further and introduced Tambora Linear 100, an advanced line of static LED Pixel mapping bars designed for versatile lighting effects and artistic set decoration.

These are hybrid bars, which incorporate two complementary effects into one fixture.  The first is driven by a system of 400 RGB pixel LEDs, which offer a background light very similar to that of a high-definition LED wall in appearance. This LED array can be controlled as 16 LEDs in 25 groups to provide high-quality motion graphics.

The second effect is created by a central line of 200 extremely powerful white LEDs for an overwhelming strobe effect, capable of reproducing the behavior of the most celebrated strobe fixtures on the market. This effect can also be controlled through 25 different areas, offering unparalleled versatility.

All graphic content can be managed through Advanced Layer Management, an exclusive feature of Claypaky LED bars, with which you can choose to use different levels of effects simultaneously, giving free expression to your creativity.

Tambora Linear 100 features many built-in effects, so it can be used in advanced mode and in a simple mode whenever a media server is unavailable, or the installation requires a speedy solution.

The Tambora Linear 100 can be easily connected mechanically with multiple units and then operated as one complete fixture from the control software. This is extremely easy and user-friendly to use. For greater compositional modularity we also offer Tambora Linear 60, a compact model particularly suitable for applications in narrow environments.

Claypaky also offers a wide range of easy-to-apply accessory filters. These can shape the beam of light with a frost effect or increase the readability of the pixels with the “neutral density” filter, which is particularly useful for television applications and enhances the on-camera performance.

Tambora Linear 100 is both sleek and lightweight and has been designed with a slim body, to better adapt to many applications. from TV studios to touring, where the need for pixel-mapping light sets is increasingly in demand and appreciated. The “hybrid” nature of Tambora is perfect for this need and provides a two-in-one versatility.  This is a truly distinctive product within each lighting set, at a truly competitive price.

  • Light Source
    400pcs 3-in-1 RGB LEDs and one line of strobe (200pcs white LEDs)
  • Light Output
    9414 Lumen Output (Integrating Sphere)
  • Effects
    400pcs 3-in-1 RGB leds, splitted into 25 areas; 200pcs white leds, splitted into 25 areas; Advanced Layer Management; White CT emulation 2800-8000K; RGB and Strobe Shape effect; Electronic linear dimmer, 24 bit and 5 curves; Electronic strobe/stop from 0.3 to 25 f/sec
Data Sheet DMX Channels Photometrics PDF

Highlights

Specs

Save as pdf and print

LIGHT SOURCE

  • Source type:
    • RGB LED (x 400)
    • White LED strobe (x 200)
  • LED life expectancy: 50.000Hrs  L70*
    *It may vary depending on various factors, as type of use and environment

PHOTOMETRIC DATA

  • Zoom range:
    • RGB LED: 72° @50% / 115° @10%
    • White LED strobe: 120° of beam aperture
  • Lm output: 26.526 Lm (integrating sphere)
  • Optical syt.: High efficiency

NOISE LEVEL

  • Controlled by: Able to control linearly the speed of the fans
  • Fixed presets:
    • Silent mode: 26.2 dBA
    • Theatre: 26.2 dBA
    • Constant: 45.3 dBA
    • Auto mode: 43.9 dB

CONTROL and CONNECTIONS

  • Personalities:
    • 5 modes with 9 / 13 / 31 / 39 / 33 control channels
    • Pixel engine: 75 channels
    • strobe engine: 25 channels
  • Protocols:  DMX , Art Net, sACN, RDM
  • Connectors:
    • Locking 5 pin XLR IN/ OUT
    • RJ45 IN /OUT
  • Power con: PowerCon True1 IN/OUT
  • Web server: Built in
  • CloudIO: Fully compatible

DYNAMIC EFFECTS

  • Colors:
    • 400 pcs 3-in-1 RGB LEDs split into 25 areas
    • 200 pcs white LEDs split into 25 areas
    • Advanced layer management:
      • Color
      • Internal Shape
      • Pixel mapping
      • Strobe
    • White CT emulation 2800 – 8000 K
    • RGB and strobe shape effect
  • Frost:
    • Black filter (Optional)
    • White filter 20° (Optional)
    • White filter 30° (Optional)
  • Dimmer/Shutter:
    • High resolution electronic Dimmer - 24 bit, 5 curves
    • Electronic strobe/stop from 0.3 to 25 f/sec.

HARDWARE and SOFTWARE

  • Long life self-charging battery
  • Display Graphic LCD backlit b/w Display
  • Firmware upload from another fixture
  • Firmware Upgrade via Web Server
  • Diagnostic
  • DMX monitoring
  • Remote access through RDM

HOUSING

  • Aluminum and steel structure with plastic covers
  • One side handle for transportation
  • IP20 protection rate
  • Built-in alignment fixture
  • Working in any position
  • Hanging system: with long bracket
  • Optional safety chain

ELECTRICAL

  • Operating voltage: 100-240V, 50/60 Hz
  • In/Out MAX: In/Out Max: 5(1) fixtures @200-240Vac – Max: 2400W
  • Power Supply: Electronic auto range with active PFC
  • MAX power consumption: 440 W

THERMAL SPECIFICATION

  • Max ambient temperature: 45°C (113°F)
  • Min ambient temperature: -20°C (-4°F)
  • Max temperature of the external surface: 90°C (194°F)
  • Total heat dissipation: 1503 BTU/hr ±10% / 1584 kJ/hr ±10%

SAFETY SPECS

  • Minimum distance of illuminated objects: 0.5 meters (1’ 8”)
  • Minimum distance from flammable materials: 0.2 meters (8”)
  • Protection:
    • Fuse T10A – 250V
    • Thermally protected power supply (overheating and cooling failure)
    • Forced ventilation with axial fans

COMPLIANCE

  • CE Marking (in conformity to the following:
    • 2014/35/EU Low Voltage Directive (LVD)
    • 2014/30/EU Electromagnetic Compatibility (EMC)
    • 2011/65/EU Restriction of the use of certain hazardous substances (RoHS)
    • 2009/125/EC EcoDesign requirements for Energy related Products (ErP)
  • UKCA: conforms to UK Regulations:
    • S.I. 2016 N. 1101
    • S.I. 2016 N. 1091
    • S.I. 2012 N. 3032
    • S.I. 2021 N. 745
  • cMETus Listed:
    • UL 1573:2003
    • CSA C22.2 N. 166:2015

PACKAGING

  • Carton box + Polystyrene
  • Carton box + Foam shell
  • Flight case + Foam shell (4 positions)

WEIGHT - SIZE

  • Weight: 5.7Kg (12.56 lbs)
  • Dimension:
    • 1000 x 74 x 172 mm
    • 39.7" x 2.9" x 6.77" In

ACCESSORIES

  • ETL Power: CAB02B-802
    • cord 1.5mt. bare end with IP65 PowerConTrue1 connector (included)
  • Omega bracket A: 409002-801 (included) x 2
  • Handle: VOL011-001 (included) x 2
  • Neutral density filter: 409010/001 (Included)
  • Adjustable bracket: 409001/801 (Included)
  • Omega bracket B: CA2004000200 (optional)
  • Floor stander: CA2003000200 (optional)
  • Black Frost Filter: CA2002000200 (optional)
  • White Frost Filter 20°: CA2000000200 (optional)
  • White Frost Filter 30°: CA2001000200 (optional)
  • Foam shell: F21331-001 (optional)
  • Flight case (4 positions.): CF1018F (optional)
  • Safety Chain: 105041-003 (optional)
  • Clamp: C21070 (optional)
